Charge and discharge data, users can query as needed. The intelligent charging/discharging detector is a product that combines charging, discharging, single-unit detection, online monitoring and activation. It has a high degree of integration and perfect functions. Through the capacity test of the battery, the backward battery can be accurately and quickly found and the remaining capacity of each unit cell can be given, and by activation, each battery of the battery pack can quickly increase the capacity and reduce the internal resistance. Effectively solve the imbalance of the cell voltage.
Main features and functions
Display mode: large LCD display, Chinese menu prompt, real-time display of all test data: the entire battery voltage, cell voltage, current, capacity, duration and internal temperature.
 Control mode: single-chip control, through the keyboard to set the charging voltage, float voltage, discharge termination voltage, charge / discharge current, duration, capacity and other parameters.
Real-time online tour detects each cell's battery parameters and automatically completes testing and monitoring of various parameters of the battery pack.
It can quickly and accurately find the failed battery and the backward battery in the battery pack through rapid discharge in a short time, estimate the remaining capacity of the battery and evaluate the quality of the battery.
Working mode:

          (1) Constant current discharge mode automatically completes the capacity test or load capacity test of the battery, and can estimate the remaining capacity of the battery through five minutes of rapid discharge for capacity analysis.
          (2) Intelligent three-stage charging mode: constant current technology is adopted in the initial stage of charging, charging current is constant, battery voltage is quickly increased, and charging voltage is applied.

When the upper limit voltage is reached, it is automatically converted into constant voltage current-reducing charging, which effectively improves the capacity conversion efficiency of the battery. At the end of charging, it is converted into turbulent floating charge, so that each unit battery is balancedly charged, ensuring maximum recovery of battery capacity. Solve the imbalance of the cell voltage and avoid the danger of overvoltage charging of the battery.

         (3) Cyclic discharge charging function: set the high/low limit of the discharge/charge hour rate and its voltage, and automatically cycle one discharge and charge cycle.

          (4) Battery activation function: Set the number of charge and discharge cycles, use pulse charging to activate and repair the battery.

Automatic stop function: automatically stop when any of the following conditions are met: time to, capacity to, single protection voltage to, the whole set of protection voltage to, the number of cycles to wait.
Automatic alarm function: It has intelligent anti-reverse function, and automatically alarms when there is high temperature or battery pack disconnection, undervoltage, overvoltage, overcurrent, etc.
Real-time monitoring function: Real-time display and control of each set of parameters (such as the entire battery voltage, cell voltage, current, capacity, duration and internal temperature).
Record inquiry function: charge/discharge detector can store 16 groups
Data dump function: with standard USB interface and RS232 interface. After the charging is completed, the data can be directly uploaded to the computer through the U disk dump or RS232 interface, which solves the problem of large-capacity data storage.
Data processing function: The charging and discharging data can be automatically generated by various matching data processing software and processed to support printing.
Computer remote control function: The charging and discharging parameters can be set and modified by the computer; the charging/discharging detector can be controlled to start and stop charging and discharging.
Calibration correction function for voltage and current display values: It can calibrate and correct the total battery voltage, cell voltage and current.
Power consumption components are made of special alloy resistors, proprietary intellectual property rights patented technology, high power density, no open flame, safe and reliable, long life.
Modular design, high degree of automation, easy operation, high charge reduction rate, energy saving and other significant features. Small size, easy to carry, forced air cooling.
