The intelligent battery discharge meter is an instrument for maintenance and capacity detection of battery packs, DC power supplies, and UPS backup batteries. Constant current / constant resistance / constant power three discharge modes, after the parameter setting, the capacity test of the battery pack or the load capacity detection of the DC power supply is automatically completed. With a standard USB interface, you can directly read data with a USB flash drive, solving the problem of large-capacity storage. The supporting data processing software has powerful online monitoring and analysis processing functions, which can obtain the working status and parameters of the discharge instrument in real time, generate various charts and display and print, and the performance of the battery and DC power supply can be seen at a glance.
1, large LCD screen display, Chinese menu prompt, single-chip control, high degree of intelligence, after parameter setting, automatically complete the battery pack capacity test or DC Source heart load capacity test.
2. Three kinds of conditions for terminating discharge can be freely set, and the discharge is automatically terminated when any condition is reached: the minimum protection voltage, discharge capacity, and discharge duration of the battery pack.
3. The power consumption part is produced by using new components and proprietary intellectual property rights patent technology. It has high power, no open flame, safety and long life.
4, computer settings, control functions: supporting data processing software, intelligent control, to achieve computer monitoring.
5, small size, easy to carry: the host is integrated design of monitoring circuit and power components, new power components, forced air cooling.
6. It can be used together with our company's XJ series battery parameter online monitor to detect the cell voltage and analyze the remaining capacity of the battery to make the battery worse. It is detected to ensure the reliability of the battery pack.
● Keyboard setting: Users can set parameters such as discharge current, protection voltage, discharge capacity and discharge duration according to battery capacity or detection requirements.
● Real-time monitoring function: display the parameters of each setting (such as voltage, current, time, etc.) in real time.
● Perfect automatic protection function and alarm function: The discharge instrument is equipped with undervoltage, high temperature, reverse connection and power failure automatic protection functions, and can sound alarm sound.
● Record query: The discharge meter can store 8 discharge data (10 hours each time), and the user can query as needed.
● Real-time communication: It can communicate with PC directly through RS232 interface to realize computer monitoring control, data analysis and processing.
● Calibration correction function for voltage and current display values: Mainly calibrate the total voltage and current of the battery pack.
● Data dumping and processing function: After the discharge is finished, the data is transferred to the U disk or uploaded to the computer via the RS232 interface. After the background processing, various charts can be automatically generated.
Provide a scientific basis for judging the merits of the battery pack.
● Computer control function: The computer can obtain the status information of the discharge instrument at any time, control the discharge instrument to start, stop or suspend the discharge; can set and modify the discharg
Instrument discharge parameters; select discharge device discharge mode.
The discharge data of the discharge instrument can be directly obtained, processed and analyzed, and the current resistance power voltage curve and the inspection data detail table can be viewed and printed. According to these charts, you can check the battery's performance trends, test data, shutdown alarms, etc., so that the performance of the battery pack is intuitively displayed.
● It can directly monitor and control the discharge meter, and it is truly unattended.
● It can obtain the status information of the discharge meter (stop state, constant current discharge state, constant resistance discharge state or constant power discharge state);
● The discharge parameters (setting parameters and operating parameters) of the discharge meter can be obtained;
● Control the discharge meter to start, stop or pause the discharge;
● PC set and modify the discharge parameters of the discharge meter;
● Select the discharge mode of the discharger;
● Start/stop online monitoring;
● The PC can transfer the historical data of the discharge of the discharge instrument at any time.
Technical Parameters:
● Connected load voltage: DC 12V/24V/48V/110V/220V/400V/600V series
● Rated current: 20A/40A/60A/80A/100A/150A/200A/400A/500A/800A series
● Battery pack nominal capacity: 50Ah-5000Ah series
● Current adjustment accuracy: 1A
● Constant current discharge control accuracy: 1%
● Working power supply: AC single phase 220V
● Heat dissipation method: forced air cooling
● Ambient temperature: -10 ° C - +50 ° C
● Specifications: voltage DC12V-600V, current 20A-800A
