Single-unit detection The whole group of discharge meters is mainly used for daily maintenance, capacity detection, regular deep discharge, and engineering acceptance of battery packs of communication operators, electric power, and power plants. It has three functions: detection unit and whole group voltage, constant current discharge and on-line monitoring. It can detect the voltage, total voltage and current parameters of each unit cell at the same time of constant current discharge, and discharge through the matching data processing software. The collected data information is processed to generate a residual capacity analysis report, which is multi-purpose and fully functional. Reduce business costs and reduce the labor intensity of maintenance personnel.

Main features and functions:

       ● Display mode: large LCD display, Chinese menu prompt, real-time display of all test data: the entire battery voltage, single battery voltage, current, capacity,
        Duration and internal temperature.
       ● Control mode: single-chip control, through the keyboard to set the parameters of the single and the entire battery voltage, discharge current, discharge capacity, discharge duration and other parameters.
       ● Fast capacity analysis function: The remaining battery capacity can be estimated by five minutes of discharge.
       ● Automatic stop function: Automatically stops discharging when any of the following conditions are met: time to, capacity to, single protection voltage to and the entire set of protection voltages.
        ● Automatic alarm function: Automatically alarms when there is high temperature or the battery pack is disconnected. Real-time monitoring function: display and control the parameters of each setting in real time
       Number (such as the entire battery voltage, cell voltage, current, time, capacity and temperature, etc.).
        ● Record inquiry function: The discharge meter can store 8 sets of discharge data (10 hours each time), and the user can query as needed.
        ● Data dump function: It has standard USB interface and RS232 interface. After the discharge is completed, the data can be directly uploaded to the meter through the U disk dump or RS232 interface.
       Computer, solves the problem of large-capacity data storage
       ● Data processing function: After the discharge data is analyzed and processed by the matching data processing software, various curve charts can be automatically generated and printed.
       ● Computer remote control function: The discharge parameter can be set and modified by the computer; the discharge meter can be controlled to start and stop discharging.
       ● Calibration correction function for voltage and current display values: It can calibrate and correct the total battery voltage, cell voltage and current.
       ● Power consumption components are made of special alloy resistors, proprietary intellectual property rights patented technology, high power density, no open flame, safe and reliable, long life.
       ● Control circuit and power consumption components are integrated design, small size, easy to carry, forced air cooling.
